PC | |
CPU | on board Intel® Celeron J1900 2.0GHz quad cores,fanless |
CPU optional | Inter® Core i3-3217, dual core, 1.8Ghz / i5-3317U, dual core, 1.7Ghz |
| Inter® Core i3 6100U 2.3Ghz / 7100U 2.4Ghz |
| Inter® Core i5 6200U 2.3Ghz,up to 2.8Ghz / 7200U 2.5Ghz,up to 3.1Ghz |
Memory | 2G DDR3 ( Max. 16G) |
Hard Drive Capacity | 32G SSD or 320G HDD |
Hard Drive Optional | SSD: 32GB,64GB,128GB, 256GB |
| HDD: 320GB,500GB,1TB |
Graphics | CPU Integrated graphics HD Graphics and support 1080p HD photo quality |
Audio | Realtek ALC662, High Definition Audio (HD), Line in, Line out |
Network | 1×Realtek RTL 8111E Gigabit Ethernet controller |
Wireless Network | Built-in W-Lan Antenna(802.11b/g/n) |
I/O Interfaces | 2×USB2.0, 2×USB3.0,1×Lan(RJ45),2 x COM(RS232/Serial), 1×VGA/HDMI/Audio OUT/POWER DC; 6xCOM (5xRS232,1xRS485) optional |
Extension interface | Mini-PCIE, support WIFI/3G/4G/MSTA |
Operation System | Windows 7/8/10 test version (with license optional), Ubuntu, Linux optional |
LCD panel | |
Panel size | 15"(4:3) |
Display Area | 304.128 (H) x 228.096(V) |
Resolution | 1024*768 |
Brightness (cd/m²) | 350cd/m2, high brightness 500~1500cd/m2 optional |
Response time | 8ms |
Contrast ratio | 700:1 |
View angle | 80°/80°/75°/80° (R/L/U/D) |
Touch panel | |
Touchscreen Type | capacitive touch panel ( tempered glass without touch optional) |
Touch Interface | USB |
Touch response time | <8ms |
Luminousness | 75-85% |
Power Supply | |
External Power Supply | AC 100 - 240V |
Working voltage | DC 12V |
Power consumption | ≤30W |
Operating Environment | |
Temperature range | operating: -10 to 60°C, storage :-20 to 80°C |
Relative humidity | 5%~95% @ 40° C, non-condensing |
Vibration | 5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis |
Packing Details | |
Net weight | 5kg |
Gross weight | 5.5kg |
Accessories | Power adapter, wall mounting bracket |
Other | |
Mounting (options) | 1) Wall brackets for wall-mounting, VESA 100×100mm |
| 2) Metal desl stander to support the PC |
| 3) Embedded installation, 1 sets screws provided |
Certification | CE, FCC |
Warranty | 1 year warranty |
